First-Time Builder x Turnkey Press Line Delivery
Building a 1250 to 1600 ton presswood line from zero and where the robot quote lands
A first-time presswood line builder without in-house press-cycle or signal-mapping experience is the customer most exposed to a standalone press-side robot quotation. AutoG is the automatic pallet take-out robot supplied together with the 1250 to 1600 ton hydraulic press, the palletizer and the line PLC on a single supplier contract, so the press open and close signal, the safety interlock logic and the fault handling all ship together as one tested package rather than as a third-party integration project on the install schedule.
What signal mapping actually costs when the robot and the press are bought separately
On a standalone press-side robot purchase, the work that lands on the customer's site is not the arm itself, it is the map between two controllers. The press open and close signal at roughly 80 degrees Celsius pallet discharge, the safety door interlock, the emergency stop chain covering both cabinets, the warm-up handshake at shift start, the alarm reset logic and the shift-handover screen all have to be drawn between the press PLC and the robot PLC by someone who understands both sides. The first-time owner has zero in-house experience of that map. The robot supplier has experience of its own cabinet but not of this press model. The press supplier has experience of its own controller but not of the robot cell that will be bolted next to it. The integration gap therefore lands as a separate project on the install schedule, usually paid by the buyer, usually running in parallel with commissioning, and almost always the first place where the 4 to 5 minute press cycle target slips into a 6 or 7 minute cycle before the line has produced a sellable pallet.
Why AutoG ships as a press-side component and not as a standalone robot arm
The structure of the equipment on the floor is the reason the supplier split exists at all. AutoG is a six-axis articulated robot arm with a multi-cup vacuum suction gripper, designed to take a freshly pressed pallet out of a 1250 to 1600 ton hot press at around 80 degrees Celsius and to release it onto a stacking position, and to alternate between two press stations with the same arm so a single cell serves a dual-press molded pallet main base. The 80 degree take-out window, the press open and close handshake and the one-arm-two-presses tending logic are not features a generic six-axis arm can deliver alone, they are features the line has to deliver because they live in the press, the robot and the line PLC at the same time. That is why EMP sells AutoG bundled with the press, the palletizer and the line PLC on a single contract, with Siemens and Mitsubishi PLC options proven at the supplier's factory acceptance test, instead of listing it as a freestanding robot SKU with a third-party integration scope on the side.
What changes for the first-time builder when the line ships as a turnkey press and robot package
A first pallet out of the press on the cycle the press was sold on is the deliverable a turnkey package commits to, and it is the deliverable a standalone robot quotation cannot. From the customer side this means no separate robot-cell procurement track on the side of the press purchase, no separate integrator contract to manage, no separate signal-mapping milestone on the install schedule, and no commissioning shift where two suppliers' engineers argue about who owns the press open and close bit. The capital risk of building a presswood line from zero with no in-house press-cycle experience collapses onto a single factory acceptance test, which the line supplier has already paid to learn. To find out whether a 1250 to 1600 ton press plus AutoG automatic pallet take-out robot plus palletizer plus PLC turnkey delivery fits your project tonnage target, the planned MDI grade and the available install window, send the details through the contact form below and EMP engineering will come back with a layout, an interface list and a delivery milestone schedule tied to one line PLC.
- press takt of 4 to 5 minutes and 80 degree pallet handling are referenced as line-level configuration facts, not as a standalone AutoG proprietary spec sheet
- 1250 to 1600 ton range is referenced as a presswood line press class, not as a robot payload or arm reach claim
- AutoG is described as a press-bundled line component with PLC integration on the same contract, not as a stand-alone robot product
- dual-press one-arm-two-presses logic is referenced as a line-level configuration option, not as an independent AutoG SKU promise
